Product introduction:
Kj-m1700-12lc is a CE certified high-temperature box furnace, with silicon molybdenum rod as heating element, silicon controlled rectifier and unique touch screen system, which makes the control more accurate and the graphical interface more convenient. The maximum furnace temperature is 1700 ℃. High temperature alumina coating on the inner furnace surface can improve the reflectivity and heating efficiency of the equipment, and also can prolong the service life of the instrument.
Technical parameters:
Kj-m1700-12lc is a CE certified high-temperature box furnace, with silicon molybdenum rod as heating element, silicon controlled rectifier and unique touch screen system, which makes the control more accurate and the graphical interface more convenient. The maximum furnace temperature is 1700 ℃. High temperature alumina coating on the inner furnace surface can improve the reflectivity and heating efficiency of the equipment, and also can prolong the service life of the instrument.
Technical parameters:
| model | KJ-MC1700-1LZ |
| Effective size | 120x120x130mm |
| Furnace material | Alumina refractory fiber |
| Operating temperature | Long-term less than or equal to 1 600 ℃; maximum temperature: 1 700 ℃ |
| Temperature control method | Using touch screen controller, intelligent 30- segment programmable control |
| Suggested heating rate | 0--10 ℃/min |
| Temperature control accuracy | ±1℃ |
| Heating element | Silicon molybdenum rod |
| Thermocouple | Type B |
| Shell structure | Double-layer wind-cooled electric spray structure |
| Door opening method | Sideways |
| Operating Voltage | 220V 50HZ/60HZ |
| Maximum power approx. | 2KW |
| Delivery | Door blocking one , crucible tongs 1, a high temperature glove 1 the sub , Manual 1 |
| Certification | CE, ISO certification |
| Optional | Spare silicon molybdenum rods, crucibles, computer temperature control software, etc. |
| Precautions | 1. In order to increase the life of furnace components, it is recommended that the heating rate should not exceed 10°C/min. 3. The furnace has no vacuum tightness, and it is forbidden to pass toxic or explosive gases. 4. Small cracks may appear on the surface of the furnace after a period of use . This is a normal phenomenon and does not affect normal use. Cracks can be repaired with alumina coating. |
| Warranty | One-year warranty (except for consumable parts and man-made damage) , and lifetime technical support.Special tips: 1. Consumable parts such as heating elements, quartz tubes, sample crucibles, etc. are not included.2. Damage caused by the use of corrosive gas and acid gas is not covered by the warranty |
